AS Dynamic Truck Axle Scales

Dynamic Truck Axle Scales 30 t

ESIT AS Portable Axle Scales are used for controling of high-capacity industrial weighing equipment. Each axle is weighed respectively on a platform by standing on. Weighing values and the results from the screen can be viewed via the printer that can be documented on the voucher. Plate number of vehicles on the plug and the secrets of its axle has different weight.

This product cannot be used for legal trade or calculating the net cargo weight by weighing axle weights separately.

For the usage of Portable Axle Scale , there is no need of a special station, electricity, etc.. the road can be used immediately by a suitable replacement. It can be measured by weight of the portable axle weighing system, excessive amount of space is very important in preventing violations.

It consists of two wireless communication scale platform with each other and one weighing terminal. The Weighing platform is made of lightweight, portable aluminum material. The weighing terminal is replaced inside a durable and light ABS case and works with rechargeable dry type batteries. The wireless system is bringing ease of use and so that the connection from the cable will have no problems.

Technical Specifications

AS30000

Meteorological Specifications



Capacity

30t

Section

5kg

Linearity

15kg

Repeatability

5kg

Stabilization Time

0.5sec - 3sec

Platform



Metarial

Aluminum

Protection Class

IP65

Platform Size (1 pc)

428x690x42 mm

Platform Weight (1 pc)

25kg

Material

Aluminum

Platform (1 pc)

1400x650x42 mm

Weight (1 pc)

25kg

Battery Type

2 adet AA (Alkaline or rechargable battery)

Battery Useful Life

3 Months (approx.)

Wireless Communication

20m

İndicator



Model

PWI-A

Material

Plastic Bag

IP Class

IP65

Display

128x64 graphical LCD

Tuşlar

Dust- and humidity-proof keyboard with 21 tact-type keys
