ART-2 WEIGHING INDICATOR

With its compact and state-of-the-art structure as well as its high level of sensitivity and improved functions, Esit's new generation scale indicator, ART-2, offers the users all the features they expect. The indicator has a durable ABS plastic housing, and it can either be mounted on the scale column or placed on a desk.

Double-display ART-2 indicator allows entering data in an alphabetical manner, defining codes, reporting, weighing and piece-counting, which make it a truly professional weighing instrument. It can be connected to a computer terminal and various printers.

Features;

  • Plastic housing suitable for use on scale column or desktop

  • Capability to indicate weight, message-part and total value on two different display

  • 6-digit red LED weight display

  • 9-character alphanumerical operator's display

  • Real-time date and time

  • Dust and humidity-proof membrane keyboard with tact keys

  • Alphabetic character entry similar to that in cell phones

  • Storable settings for piece counting and pricing

  • Automatic and manual multiple tare

  • Zeroing, function and adjustment keys

  • Selectable unit display options: kg / g / t / N / lbs / OZ / m / °C / °F

  • Selectable language options: TR / EN / RUS / BG / RO

  • Barcode printing: Code 39 / EAN-13

  • Battery-protected non-volatile memory

  • Gain adjustment for load cell output

  • Calibration key: on/off switch

  • Remote display output

  • RS232 serial output

  • Parallel output to printer

Options;

Accessories;
• RD Remote Display
• IC Column

Specifications.

Accuracy
Accuracy class (OIML approved) 7000d (III)
Input sensitivity 0.5µV/digit
Sensitivity 0.004%
Zero and gain stability 2.8ppm/°C
A/D converter 24bit Sigma-Delta
Digital filter Dynamic numerical filtering
Reading frequency 6-50Hz
Loadcell
Number of Loadcells allowed 8 (350ohm)
Analog input range ± 160mV/V
Excitation voltage 10V DC
Environment
Operating temperature range (OIML approved) -10°C +40°C
Storage temperature range -20°C +70°C
Operating voltage and power 220-240V AC / 12-35V DC – 8W
Operator handling and Display
Keyboard Dust and humidity-proof membrane keyboard with 20 tact type keys
Weight display 20 mm, 6-digit, 7-segment, red LED
Function display 15 mm, 9-digit, 15-segment, red LED
Program Indicator 25 mm, 8x8 dot matrix LED
Housing
Material and protection class Plastic, IP54
Weight 1.3kg
Package weight and dimensions 1.5kg, 17x30x15cm
Communication Standard                                        Optional
Serial communication output RS232 RS422 / RS485
Parallel printer output √                                                                               –
Binary (BCD) output –                                                                                –
Remote display output √                                                                               –
Digital input / output –                                                                                –
Analog output –                                                                                –

Areas Of Use

  • Industrial Scales: PS 3-100 kg Desktop Scales with Single Load Cell (6-15-30-60-100 kg)
  • Industrial Scales: PL Platform Scales (300-600-1500 kg)
  • Industrial Scales: PU Palette Scales (1500-3000 kg)
  • Industrial Scales: MR Monorail Scales (600-1500 kg)
  • Industrial Scales: CH Livestock Weighing Scales (1500 kg)
  • Industrial Scales: TT Transpalette Weighers (2000 kg)
